A mass notification system (MNS) is designed to clearly communicate with people during a catastrophic disaster or threat, steering them away from danger and toward safety. There are two MNS classifications: wide-area, providing real-time information to outdoor areas, and in-building, providing information and instruction to people inside a building by way of intelligible voice communications and often, visible signals, text, and graphics. This article will focus on a specific aspect of the in-building MNS, the voice communications of an emergency communication system (ECS) that provides fire alarm, public address, fire fighter, area of refuge, and elevator communications during an emergency. The National Fire Protection Agency (NFPA) provides code requirements for a MNS and ECS used for these purposes, as well as weather emergencies, terrorist events, biological, chemical, and nuclear emergencies, and other threats. The NFPA code referred to in this article is the NFPA 72® National Fire Alarm Code® 2010 and 2013 editions.
The NFPA added two new terms related to building communications to its National Fire Alarm Code® revision in 2010: acoustically distinguishable space (ADS) and speech intelligibility. An ADS is a space that is acoustically different from adjacent spaces and therefore requires a different approach to the design of the adjacent spaces: translated into code-speak, this space is “an emergency communications system notification zone, or subdivision thereof, that might be an enclosed or otherwise physically defined space, or that might be distinguished from other spaces because of different acoustical, environmental, or use characteristics, such as reverberation time and ambient sound pressure level.” An example of an ADS could be a multi-story atrium adjacent to low-ceiling concourses. Speech intelligibility, as the name implies, is a measure of the actual understandability of speech when all factors (acoustics of the space, background noise levels, and sound system design) are considered. These terms have greatly changed the design of communication systems for buildings.
Prior to the National Fire Alarm Code® 2010 and 2013 edition changes, fire protection engineers were required to design systems to be audible, which meant announcements were louder than the ambient noise in the space by 15 dBA (the logarithmic scale used to measure levels of sound). This design approach applied to all types of acoustic spaces and did not address the complexities of room acoustics, ambient noise control, and transducer (loudspeaker) selection, often resulting in audible announcements that were not intelligible.
Millions of people visit large, complex buildings such as transportation hubs, healthcare facilities, convention centers, and casinos every year. Emergency communications in these facilities must be clear to prevent panic, injury, and loss of life, particularly because the visitors to these types of buildings generally are not familiar with the facility and have difficulty finding a safe exit path without explicit instruction. To illustrate this point, let’s consider what people might experience in an airport.
Travelers at an international airport arrive at an expansive four- or five-story open space in the main terminal that houses ticketing; security, international arrivals, baggage claim, and concourse areas with restaurants and retail shops may be in separate areas with lower ceilings and completely different architectural finishes. Each of these airport areas is an ADS, perhaps zoned into smaller ADSs depending on the architecture. The reverberation time and background noise level (ambient sound pressure level) are factors that must be considered by acousticians and designers during the design of the ECS in order to provide the specified level of intelligibility, a threshold determined by the Speech Transmission Index (STI) set forth by the International Electrotechnical Commission (IEC).
As an example, a traveler may arrive to acoustic bedlam in the main terminal due to the non-absorptive finishes throughout the terminal. The finishes cause a buildup of reverberant sound, making it almost impossible to understand a talker only a few feet away from a listener. The paging system is operational, but only adds to the background noise. The traveler cannot understand the announcements due to the high reverberation time and the poor location of loudspeakers. The high noise levels and inability to understand courtesy and information announcements only add to the travelers’ anxiety. If a catastrophic event occurs, the traveler will not be able to understand the announcements.
Contrast that to a similar main terminal that is just as active but with generous absorptive finishes that provide a relaxing atmosphere, allowing the traveler to easily orient to his surroundings. The paging system has been designed to provide courtesy and information announcements clearly and at a conversational level. Emergency announcements are clear and concise, providing straightforward direction and guidance to the travelers.
The changes in the NFPA-72® National Fire Alarm Code® 2010 and 2013 editions finally bring intelligibility to the forefront in the design of emergency communication systems. Designers and engineers working with the building owner and architect can optimize the acoustics and systems in each acoustically distinguishable space to provide clear, intelligible communications, often without increasing the cost of the systems significantly. The end result is a facility with intelligible communication systems that may reduce panic, injury, and loss of life during a crisis.
Richard Closs, CTS-D, director of systems at Acentech.
